Providing a Variety of Superior Manufacturing Services
Global Tool uses the most up-to-date software to design in both 2D and 3D. Using Solidworks, AutoCAD, and Feature CAM, our engineers translate a wide variety of data files and begin the development process before receiving a sample part to guarantee efficiency and fast turnaround of your product
EXPERIENCE
In the design and development process, Global Tool’s engineers use years of industry experience to construct the best trim tools for your needs. With more than thirty years in the field, we combine traditional know-how with contemporary expertise to advise you on the best trim solution for your specific needs.
PARTNERSHIP
We collaborate with you as partners through the entire design and development process, consulting you each step of the way to determine the absolute best trim tool for your specific needs.
SATISFACTION
By working with Global Tool’s most experienced engineers as your strategic partners, we hope to ensure complete satisfaction of all your tooling needs.
Trim Dies
The design, build and repair of trim dies (upper compound, lower compound, double compound and push through trim dies) represents a significant portion of Global Tool's business for the die casting industry.
We work closely with our customers from the preliminary stage of design to the completion of a project, ensuring the development of a tool that best fits your needs. All tooling is built to print specifications using premium quality tool steels, fully certified by Global Tool.
Operations inside the tooling include:
- Mechanical side action slides (proprietary technology)
- Hydraulic side action slides
- Multiple trim stations
- Positive knockout systems
- Drilling and tapping
- Part marking/labeling
- Automated air blow-offs
Global Tool designs and builds CNC fixtures that are competitively priced with operational efficiency in mind. Designed with either hydraulic, pneumatic, or hand clamps, all fixtures are tailored to specific customer needs. Wear components come standard.
“We can build anything from simple, hand-operated fixtures to stand-alone fully automated stations.”
- Machining Fixtures
- Hand-Operated Fixtures
- Leak Test Fixtures
Global Tool designs and builds high-quality progressive stamping dies, blanking dies, and lamination dies from a wide range of materials. Designed in 2D or 3D, our dies are then machined with maintenance in mind and are easy to disassemble, minimizing downtime and maximizing efficiency.
Global Tool's goal is to extend the life of a tool through a long-term repair & maintenance solution rather than a temporary "band-aid" approach. Our expert staff takes great pride in workmanship and uses only premium quality steels for all components.
Our comprehensive capabilities include in-house welding and tool sampling, which enable us to provide fast turnaround and competitive pricing. We stock a wide array of components to help facilitate quick repairs. Nationwide delivery is available!
CNC Machining
Global Tool provides precision CNC machining of prototypes and short-run parts, including quality-machined castings in a variety of materials.
Our state-of-the-art vertical CNC machining center includes linear scales, through spindle coolant, and operates at speeds up to 15,000 rpm.
Global Tool's skilled programmers coupled with our advanced CAM software ensure maximum efficiency, saving valuable time with programming and set-up.
Wire EDM
Our state-of-the-art in-house wire EDM machines offer the flexibility to cut a wide range of materials, from tool steel to aluminum to carbide. Global Tool's capabilities include workpieces up to the following specifications:
- Maximum workpiece dimensions: 44" x 32" x 16.2"
- Maximum workpiece weight: 3600 lbs
- Table travels: 23.6" x 15.7" x 16.2"
- Maximum taper angle: 30°
- Accuracy: ±0.0001"
